Research Metallurgical Microscope IMM-3490 is a part of the range of research microscope and stands out through its design which is ergonomic, vigorous and constant and stable. This research microscope is used to view samples that will fit on the microscope stage. This range, with its large working distance infinite plan achromatic: 5X/ 0.12/∞/ - (BF)-15.5 mm, 10X/ 0.25/∞/-(BF)-10.0 mm, 20X/ 0.4/∞/ 0 (BF)-5.8 mm, 50X/ 0.75/∞/ 0 (BF)- 0.32 mm, 100X/ 0.8/∞/ 0 (BF)-2.0 mm objective. Adjustable 40W LED reflected lamp to ensure the optimum illumination of the materials to be tested. The illuminating system consists of a high-intensity light source. The trinocular viewing head with extra wild field EW10X22 mm eyepieces fitted with 48-75 mm interpupilary distance as standard. Blue, Green, Yellow and Frosted filters. Designed with coaxial coarse and fine adjustment focusing. Features with backward quintuple revolving nosepiece holds multiple lenses, and found between the eyepiece and the stage allowing the user to turn it to achieve various levels of magnification. Though the exact level of magnification may vary with different models, most microscopes provide a low power lens with about 5X magnification and a high power lens with about 100X magnification
Data sheet
| Model | IMM-3480 | IMM-3490 |
| Type | Research Metallurgical Microscope | |
| Viewing Head | Trinocular head, at 30°, rotate360°, interpupillary distance 48-75mm | |
| Optical System | Infinite | |
| Focusing | Coaxial coarse and fine adjustment, Fine Division 0.001mm, Moving Range 32mm | |
| Eyepiece | EW10X22mm | - |
| Nosepiece | Backward quintuple | |
| Objective | Infinite Plan Achromatic:5X/ 0.12/?/ - (BF)-15.5 mm, 10X/ 0.25/?/ - (BF)-10.0 mm, 20X/ 0.4/?/ 0 (BF)-5.8 mm, 50X/ 0.75/?/ 0 (BF)- 0.32 mm, 100X/ 0.8/?/ 0 (BF)-2.0 mm | Infinite Plan Achromatic: 5X/ 0.12/?/ - (BF&DF)-12.0 mm, 10X/ 0.25/?/ - (BF&DF)-10.0 mm, 20X/ 0.4/?/ 0 (BF&DF)-4.3 mm, 50X/ 0.75/?/ 0 (BF&DF)-32 mm, 100X/ 0.8/?/ 0 (BF&DF)-2.0 mm |
| Light Source | 40W LED Reflected(optional) | |
| Polarizing Unit | optional | |
| Analyzing Unit | ||
| Filter | Blue, Green, Yellow and Frosted filter | |
| Certification |
|
|
| Optional Accessories | Specimen Presser, Photo Attachment for Nikon or Canon DSLR camera, Video Attachment, C-Mount 1X, 0.5X | |
| Packing Dimension |
|
|
| Packing Weight |
|
|
| Electrical Requirement |
|
|
| Catalogue No. | 440305-05-04 | 440305-10-04 |
