The Iris ITR-1020 real time PCR is applicable for real-time detection in farming, breeding, pasteurization, and water sources along with other useful application for detecting and diagnosis epidemic disease, inspection and quarantine in the field of food safety and R & D sectors.
The Iris ITR-1020 real time PCR is applicable for real-time detection in farming, breeding, pasteurization, and water sources along with other useful application for detecting and diagnosis epidemic disease, inspection and quarantine in the field of food safety and R & D sectors. ITR-1020 is fluorescence quantitative PCR types with Marlow custom peltier design.
Data sheet
Model | ITR-1010 | ITR-1020 | |
Capacity | 16x0.2 ml(2x8 well, dual block) | ||
Reaction Volume | 10 to 100 µl | ||
Display | 7 inch TFT Display | ||
Temperature Range | 0 to 100°C | ||
Resolution | 0.1 °C | ||
Uniformity | ± 0.25 °C | ||
Accuracy | ± 0.25 °C | ||
Temperature Control | Block/Tube | ||
Sensitivity | 1 Copy | ||
Test Dynamic Range | 1 to 1010 Copies | ||
Fluorescent Dye | F1:FAM/SYBR Green I, F2:HEX/VIC/JOE/TET | ||
Channel | Single Channel | Dual Channel | |
Ramping Rate | 6 °C/s | ||
Hot Lid Temperature | 30 to 115°C (Default 105°C) | ||
Excitation Wavelength | 460 to 550 nm | ||
Emission Wavelength | F1: 520 to 540 nm | F1: 520 to 540 nm & F2: 540 t0 580 nm | |
Detector | Photoelectric Detector | ||
Function | Absolute/Relative Quantifications/Melting curve/Genotyping | ||
Connectivity | Wi-Fi, USB2.0 | ||
Power Consumption | 250 W | ||
Dimensions | 300x267x198 mm | ||
Weight | 5.5 kg | ||
Electrical Requirements | DC15 V | ||
Catalogue No. | 6005005-00 | 6005010-00 | |
| Model | ITR-1010 | ITR-1020 | |
| Capacity | 16x0.2 ml(2x8 well, dual block) | ||
| Reaction Volume | 10 to 100 µl | ||
| Display | 7 inch TFT Display | ||
| Temperature Range | 0 to 100°C | ||
| Resolution | 0.1 °C | ||
| Uniformity | ± 0.25 °C | ||
| Accuracy | ± 0.25 °C | ||
| Temperature Control | Block/Tube | ||
| Sensitivity | 1 Copy | ||
| Test Dynamic Range | 1 to 1010 Copies | ||
| Fluorescent Dye | F1:FAM/SYBR Green I, F2:HEX/VIC/JOE/TET | ||
| Channel | Single Channel | Dual Channel | |
| Ramping Rate | 6 °C/s | ||
| Hot Lid Temperature | 30 to 115°C (Default 105°C) | ||
| Excitation Wavelength | 460 to 550 nm | ||
| Emission Wavelength | F1: 520 to 540 nm | F1: 520 to 540 nm & F2: 540 t0 580 nm | |
| Detector | Photoelectric Detector | ||
| Function | Absolute/Relative Quantifications/Melting curve/Genotyping | ||
| Connectivity | Wi-Fi, USB2.0 | ||
| Power Consumption | 250 W | ||
| Dimensions | 300x267x198 mm | ||
| Weight | 5.5 kg | ||
| Electrical Requirements | DC15 V | ||
| Catalogue No. | 6205005-00 | 6205010-00 | |
