Iris orbital shakers feature a rectangular platform that moves in a circular motion to aerate samples. Additional features for all of these units include intuitive controls with a digital display, a robust construction in a compact, space-saving design and smooth running conditions with variable speeds.
The IS-3300 Incubator Shaker provide orbital/reciprocating shaking function, adjustable shaking speed and timer function for maximum flexibility.
Iris incubator shakers feature a rectangular platform that moves in a circular motion to aerate samples. Additional features for all of these units include intuitive controls with a digital display, a robust construction in a compact, space-saving design and smooth running conditions with variable speeds. Our laboratory shakers allow for safe, efficient and easy-to-use operation while reproducing accurate, controlled speeds with every use.
Applicable for fermentation processes with high demands on the precision of the shaking frequency, bacteria incubation, hybridization, life science, pharmacy, medical science, food industry, chemistry, biology, and other laboratory environments.
Multi-function Shaking System:
The IS-3300 incubator shaker's intensive multifunction shaking system surpasses all previous levels of experience! You can multi-set the shaking motions in many ways of Forward/ Backward/ Pause/ Mix & match upon your various laboratory purpose.
Data sheet
Model | IS-3300 | IS-3300R | IS-3600 | IS-3600R | ||||
Volume (L) | 53 | 53 | 83 | 83 | ||||
Temperature Range (?) | Ambient +5 ~ 60°C | 15 - 60°C | Ambient +5 ~ 60°C | 15 - 60°C | ||||
Temperature Accuracy (?) | ±0.1 (38?) | ±0.1 (38?) | ±0.1 (38?) | ±0.1 (38?) | ||||
Temperature Stability (?) | ±1.0 (38?) | ±1.0 (38?) | ±1.0 (38?) | ±1.0 (38?) | ||||
Temperature Controller | Touch Control; Digital Display with PID automatic regulation | Touch Control; Digital Display with PID automatic regulation | Touch Control; Digital Display with PID automatic regulation | Touch Control; Digital Display with PID automatic regulation | ||||
Temperature Heater | Heating Plate, 600W | Heating Plate, 600W | Heating Plate, 600W | Heating Plate, 600W | ||||
Temperature Timer | Start / Stop / Duration setting; 10sec ~999hr 59min 59sec | Start / Stop / Duration setting; 10sec ~999hr 59min 59sec | Start / Stop / Duration setting; 10sec ~999hr 59min 59sec | Start / Stop / Duration setting; 10sec ~999hr 59min 59sec | ||||
Shaker Controller | PID automatic regulation | PID automatic regulation | PID automatic regulation | PID automatic regulation | ||||
Shaker Power Unit | Brushless motor | Brushless motor | Brushless motor | Brushless motor | ||||
Shaker Methods | Clockwise, Counter-clockwise, forth-back, interrupted, | Clockwise, Counter-clockwise, forth-back, interrupted, | Clockwise, Counter-clockwise, forth-back, interrupted, | Clockwise, Counter-clockwise, forth-back, interrupted, | ||||
Shaker Shaking Throw (mm) | 20, 30 (standard), 40 | 20, 30 (standard), 40 | 20, 30 (standard), 40 | 20, 30 (standard), 40 | ||||
Shaker Speed (rpm) | 10?300 | 10?300 | 10?300 | 10?300 | ||||
Shaker Stability (rpm) | ±1 (150rpm) | ±1 (150rpm) | ±1 (150rpm) | ±1 (150rpm) | ||||
Platform Dimensions (W × D in mm) | 330 x 330 | 330 x 330 | 410 x 410 | 410 x 410 | ||||
Inside Dimensions (W × D × H in mm) | 410 x 410 x 320 | 410 x 410 x 320 | 510 x 510 x 320 | 510 x 510 x 320 | ||||
Outside Dimensions (W × D × H in mm) | 440 x 740 x 625 | 440 x 740 x 625 | 540 x 850 x 625 | 540 x 850 x 625 | ||||
Maximum Load (kg) | 10 | 10 | 15 | 15 | ||||
Net Weight (kg) | 74 | 85 | 91 | 102 | ||||
Gross Weight (kg) |
|
|
|
| ||||
Shipping Weight (kg) |
|
|
|
| ||||
Shipping Dimensions (mm) |
|
|
|
| ||||
Electrical Requirements | 110V/60Hz | 220V/50Hz | 110V/60Hz | 220V/50Hz | 110V/60Hz | 220V/50Hz | 110V/60Hz | 220V/50Hz |
Catalogue No. | 54025051 | 54025052 | 54025101 | 54025102 | 54025151 | 54025152 | 54025201 | 54025202 |
| Model | IS-3300 | IS-3300R | IS-3600 | IS-3600R | ||||
| Volume (L) | 53 | 53 | 83 | 83 | ||||
| Temperature Range (?) | Ambient +5 ~ 60°C | 15 - 60°C | Ambient +5 ~ 60°C | 15 - 60°C | ||||
| Temperature Accuracy (?) | ±0.1 (38?) | ±0.1 (38?) | ±0.1 (38?) | ±0.1 (38?) | ||||
| Temperature Stability (?) | ±1.0 (38?) | ±1.0 (38?) | ±1.0 (38?) | ±1.0 (38?) | ||||
| Temperature Controller | Touch Control; Digital Display with PID automatic regulation | Touch Control; Digital Display with PID automatic regulation | Touch Control; Digital Display with PID automatic regulation | Touch Control; Digital Display with PID automatic regulation | ||||
| Temperature Heater | Heating Plate, 600W | Heating Plate, 600W | Heating Plate, 600W | Heating Plate, 600W | ||||
| Temperature Timer | Start / Stop / Duration setting; 10sec ~999hr 59min 59sec | Start / Stop / Duration setting; 10sec ~999hr 59min 59sec | Start / Stop / Duration setting; 10sec ~999hr 59min 59sec | Start / Stop / Duration setting; 10sec ~999hr 59min 59sec | ||||
| Shaker Controller | PID automatic regulation | PID automatic regulation | PID automatic regulation | PID automatic regulation | ||||
| Shaker Power Unit | Brushless motor | Brushless motor | Brushless motor | Brushless motor | ||||
| Shaker Methods | Clockwise, Counter-clockwise, forth-back, interrupted, | Clockwise, Counter-clockwise, forth-back, interrupted, | Clockwise, Counter-clockwise, forth-back, interrupted, | Clockwise, Counter-clockwise, forth-back, interrupted, | ||||
| Shaker Shaking Throw (mm) | 20, 30 (standard), 40 | 20, 30 (standard), 40 | 20, 30 (standard), 40 | 20, 30 (standard), 40 | ||||
| Shaker Speed (rpm) | 10?300 | 10?300 | 10?300 | 10?300 | ||||
| Shaker Stability (rpm) | ±1 (150rpm) | ±1 (150rpm) | ±1 (150rpm) | ±1 (150rpm) | ||||
| Platform Dimensions (W × D in mm) | 330 x 330 | 330 x 330 | 410 x 410 | 410 x 410 | ||||
| Inside Dimensions (W × D × H in mm) | 410 x 410 x 320 | 410 x 410 x 320 | 510 x 510 x 320 | 510 x 510 x 320 | ||||
| Outside Dimensions (W × D × H in mm) | 440 x 740 x 625 | 440 x 740 x 625 | 540 x 850 x 625 | 540 x 850 x 625 | ||||
|
|
|
|
|
| ||||
| Max. Load (kg) | 10 | 10 | 15 | 15 | ||||
| Net Weight (kg) | 74 | 85 | 91 | 102 | ||||
| Gross Weight (kg) |
|
|
|
| ||||
| Shipping Weight (kg) |
|
|
|
| ||||
| Shipping Dimensions (mm) |
|
|
|
| ||||
| Electrical Requirements | 110V/60Hz | 220V/50Hz | 110V/60Hz | 220V/50Hz | 110V/60Hz | 220V/50Hz | 110V/60Hz | 220V/50Hz |
| Catalogue No. | 54025051 | 54025052 | 54025101 | 54025102 | 54025151 | 54025152 | 54025201 | 54025202 |
| Model | Image | Name | Product Detail | Availability | Price | Action |
| 54001A02 |
|
Sticky Plate 350 x 350 mm |
The Sticky Plate can be loaded with any kind of vessel with a smooth base. Even at a speed of up to 350rpm the vessel sticks to the plate.... |
Price On Request |
|
|
| 54002A02 |
|
Universal Trays 350 x 350 mm |
The Universal Trays employ a drilled grid for individual loadings of test tube holders, microtitre plates, and deep well plates. |
Price On Request |
|
|
| 54003A01 |
|
Deep Well Plates/Clamps for Beakers 50ml |
Deep well plates/clamps made of stainless steel for beakers of different volumes. |
Price On Request |
|
|
| 54003A02 |
|
Deep Well Plates/Clamps for Beakers 100ml |
Deep well plates/clamps made of stainless steel for beakers of different volumes. |
Price On Request |
|
|
| 54003A03 |
|
Deep Well Plates/Clamps for Beakers 250ml |
Deep well plates/clamps made of stainless steel for beakers of different volumes. |
Price On Request |
|
|
| 54003A04 |
|
Deep Well Plates/Clamps for Beakers 300ml |
Deep well plates/clamps made of stainless steel for beakers of different volumes. |
Price On Request |
|
|
| 54003A05 |
|
Deep Well Plates/Clamps for Beakers 500ml |
Deep well plates/clamps made of stainless steel for beakers of different volumes. |
Price On Request |
|
|
| 54003A06 |
|
Deep Well Plates/Clamps for Beakers 1L |
Deep well plates/clamps made of stainless steel for beakers of different volumes. |
Price On Request |
|
|
| 54003A07 |
|
Deep Well Plates/Clamps for Beakers 2L |
Deep well plates/clamps made of stainless steel for beakers of different volumes. |
Price On Request |
|
|
| 54003A08 |
|
Deep Well Plates/Clamps for Beakers 2.8L |
Deep well plates/clamps made of stainless steel for beakers of different volumes. |
Price On Request |
|
|
| 54003A09 |
|
Deep Well Plates/Clamps for Beakers 4L |
Deep well plates/clamps made of stainless steel for beakers of different volumes. |
Price On Request |
|
|
| 54003A10 |
|
Deep Well Plates/Clamps for Beakers 6L |
Deep well plates/clamps made of stainless steel for beakers of different volumes. |
Price On Request |
|
|
| 54005A01 |
|
Test Tube Holders - 86 test tubes 8 mm diameter |
Holders for test tubes of different sizes and different quantities. |
Price On Request |
|
|
| 54005A02 |
|
Test Tube Holders - 86 test tubes 10 mm diameter |
Holders for test tubes of different sizes and different quantities. |
Price On Request |
|
|
| 54005A03 |
|
Test Tube Holders - 58 test tubes 12 mm diameter |
Holders for test tubes of different sizes and different quantities. |
Price On Request |
|
|
| 54005A04 |
|
Test Tube Holders - 58 test tubes 14 mm diameter |
Holders for test tubes of different sizes and different quantities. |
Price On Request |
|
|
| 54005A05 |
|
Test Tube Holders - 32 test tubes 16 mm diameter |
Holders for test tubes of different sizes and different quantities. |
Price On Request |
|
|
| 54005A06 |
|
Test Tube Holders - 19 test tubes 25 mm diameter |
Holders for test tubes of different sizes and different quantities. |
Price On Request |
|
|
| 54005A07 |
|
Test Tube Holders - 10 test tubes 35 mm diameter |
Holders for test tubes of different sizes and different quantities. |
Price On Request |
|
|
| 54013A01 |
|
Test Tube Rack 210mm x 90mm |
Test Tube Rack 210mm x 90mm with holes ∅ 30mm and ∅ 16mm |
Price On Request |
|
|
| 54013A02 |
|
Test Tube Rack 340mm x 90mm with holes ∅ 16mm |
Test Tube Rack 340mm x 90mm with holes ∅ 16mm |
Price On Request |
|
